Radiomaster Zorro ELRS Radio Transmitter without Receiver

The RadioMaster Zorro ELRS Radio Transmitter is a compact, game-controller-style radio designed for FPV drone pilots and RC enthusiasts, featuring an internal ExpressLRS (ELRS) module for long-range, low-latency control.

• ExpressLRS Internal Module: Built-in 2.4GHz ELRS module supporting a maximum RF power output of up to 250mW.
• Ergonomic Design: Features soft leather grips and a compact shape optimized for comfortable handling during long flight sessions.
• Hall Effect Gimbals: High-precision, travel-adjustable Hall sensor gimbals provide smooth and accurate stick response.
• Nano Module Bay: Includes an external module slot compatible with Nano-sized modules such as TBS Crossfire, Nano Tracer, or IRC Ghost.
• Oversized LCD Display: A 128x64 monochrome LCD screen positioned for clear visibility during operation.
• Flexible Power Options: Powered by two 18350 Li-ion batteries (not included) or an external 2S power supply via a dedicated XT30 port.
• Connectivity: Integrated USB-C port for internal battery charging (QC3 fast charging supported) and a secondary USB-C port for simulator use and firmware updates.
• Assignable Controls: Includes rear and top assignable push buttons, scroll wheels, and two three-position switches.

• Operating Frequency: 2.400GHz - 2.480GHz.
• Operating System: OpenTX / EdgeTX compatible.
• Control Channels: Maximum 16 (protocol dependent).
• RF Power: Up to 22dBm (ELRS version).
• Operational Voltage: 6.6V - 8.4V DC.
• Operational Current: 160mA @ 8.4V.
• Display: 128 x 64 Monochrome LCD.
• Dimensions: 170 x 159 x 108 mm.
• Weight: Approximately 350 - 355 grams.
• Antenna Gain: Folding 2dB antenna.
